  • DZR-LF-Thermostatic-Balancing-Valve-9960ABTC-FNPT
Designed for domestic hot water recirculation.
DZR lead free brass body / Sn/Ni galvanically plated.
Temperature activated internal flow cartridge.
Cartridge shutter will reach the open position 8°F below the fully closed temperature.
Wide range of temperature setting.
Double union body with integral check valve for easy installation and maintenance.
Union body with PPO/GF spring loaded check valve.
FNPT, Solder, EzPress and PEX F-1960 available for tailpieces.
- FNPT: ANSI/ASME B1.20.1
- Solder: ANSI B16.22
- EzPress: ASTM B88
- PEX: ASTM F1960
AB1953, NSF/ANSI/CAN 61 & 372 certified

Meets BAA requirement

250 CWP valve body rating

Working conditions
Water: 32°F - 200°F
1 - 25 of 120 | Results Per Page | View | Unit of Measure
1 2 3 4 5
Request Information Compare Items Add to CAD Cart

Item #

CAD

BIM

Size

Operating Temperature [Min]

Operating Temperature [Max]

Length

Height

Weight

9960ABTC-EE-100 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 5.85 in N/A 1.46 in N/A 1.070 lb
9960ABTC-EE-100 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 7.68 in N/A 2.05 in N/A 2.250 lb
9960ABTC-EE-100 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 6.69 in N/A 1.81 in N/A 1.640 lb
9960ABTC-EE-105 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 5.85 in N/A 1.46 in N/A 1.070 lb
9960ABTC-EE-105 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 7.68 in N/A 2.05 in N/A 2.250 lb
9960ABTC-EE-105 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 6.69 in N/A 1.81 in N/A 1.640 lb
9960ABTC-EE-110 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 5.85 in N/A 1.46 in N/A 1.070 lb
9960ABTC-EE-110 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 7.68 in N/A 2.05 in N/A 2.250 lb
9960ABTC-EE-110 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 6.69 in N/A 1.81 in N/A 1.640 lb
9960ABTC-EE-115 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 5.85 in N/A 1.46 in N/A 1.070 lb
9960ABTC-EE-115 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 7.68 in N/A 2.05 in N/A 2.250 lb
9960ABTC-EE-115 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 6.69 in N/A 1.81 in N/A 1.640 lb
9960ABTC-EE-120 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 5.85 in N/A 1.46 in N/A 1.070 lb
9960ABTC-EE-120 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 7.68 in N/A 2.05 in N/A 2.250 lb
9960ABTC-EE-120 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 6.69 in N/A 1.81 in N/A 1.640 lb
9960ABTC-EE-125 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 5.85 in N/A 1.46 in N/A 1.070 lb
9960ABTC-EE-125 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 7.68 in N/A 2.05 in N/A 2.250 lb
9960ABTC-EE-125 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 6.69 in N/A 1.81 in N/A 1.640 lb
9960ABTC-EE-130 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 5.85 in N/A 1.46 in N/A 1.070 lb
9960ABTC-EE-130 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 7.68 in N/A 2.05 in N/A 2.250 lb
9960ABTC-EE-130 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 6.69 in N/A 1.81 in N/A 1.640 lb
9960ABTC-EE-135 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 5.85 in N/A 1.46 in N/A 1.070 lb
9960ABTC-EE-135 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 7.68 in N/A 2.05 in N/A 2.250 lb
9960ABTC-EE-135 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 6.69 in N/A 1.81 in N/A 1.640 lb
9960ABTC-EE-140 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 5.85 in N/A 1.46 in N/A 1.070 lb
