  • DZR-LF-Thermostatic-Balancing-Valve-9960ABIBVC-FNPT
Designed for domestic hot water recirculation.
DZR lead free brass body / Sn/Ni galvanically plated for the TBV and the union body with check valve.
Temperature activated internal flow cartridge.
Cartridge shutter will reach the open position 8°F below the fully closed temperature.
Wide range of temperature setting.
Double union body for easy installation and maintenance.
Union body with PPO/GF spring loaded check valve.
Isolation ball valve with union nut for ON/OFF operation.
Blow-out proof stem, adjustable packing.
FNPT, Solder and EzPress version available for ball valve.
- FNPT: ANSI/ASME B1.20.1
- Solder: ANSI B16.22
- EzPress: ASTM B88
AB1953, NSF/ANSI/CAN 61 & 372 certified

Meets BAA requirement

250 CWP valve body rating

Working conditions
Water: 32°F - 200°F
1 - 25 of 90 | Results Per Page | View | Unit of Measure
1 2 3 4
Request Information Compare Items Add to CAD Cart

Item #

CAD

BIM

Size

Operating Temperature [Min]

Operating Temperature [Max]

Length

Height

9960ABIBVC-FF-100 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 7.58 in N/A 2.07 in
9960ABIBVC-FF-100 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 10.09 in N/A 2.57 in
9960ABIBVC-FF-100 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 8.43 in N/A 2.20 in
9960ABIBVC-FF-105 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 7.58 in N/A 2.07 in
9960ABIBVC-FF-105 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 10.09 in N/A 2.57 in
9960ABIBVC-FF-105 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 8.43 in N/A 2.20 in
9960ABIBVC-FF-110 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 7.58 in N/A 2.07 in
9960ABIBVC-FF-110 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 10.09 in N/A 2.57 in
9960ABIBVC-FF-110 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 8.43 in N/A 2.20 in
9960ABIBVC-FF-115 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 7.58 in N/A 2.07 in
9960ABIBVC-FF-115 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 10.09 in N/A 2.57 in
9960ABIBVC-FF-115 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 8.43 in N/A 2.20 in
9960ABIBVC-FF-120 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 7.58 in N/A 2.07 in
9960ABIBVC-FF-120 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 10.09 in N/A 2.57 in
9960ABIBVC-FF-120 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 8.43 in N/A 2.20 in
9960ABIBVC-FF-125 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 7.58 in N/A 2.07 in
9960ABIBVC-FF-125 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 10.09 in N/A 2.57 in
9960ABIBVC-FF-125 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 8.43 in N/A 2.20 in
9960ABIBVC-FF-130 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 7.58 in N/A 2.07 in
9960ABIBVC-FF-130 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 10.09 in N/A 2.57 in
9960ABIBVC-FF-130 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 8.43 in N/A 2.20 in
9960ABIBVC-FF-135 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 7.58 in N/A 2.07 in
9960ABIBVC-FF-135 1 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1 N/A 32 ºF N/A 200 ºF N/A 10.09 in N/A 2.57 in
9960ABIBVC-FF-135 3/4 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 3/4 N/A 32 ºF N/A 200 ºF N/A 8.43 in N/A 2.20 in
9960ABIBVC-FF-140 1/2 N/A CAD Icon (for items table) N/A Revit Icon (for items table) N/A 1/2 N/A 32 ºF N/A 200 ºF N/A 7.58 in N/A 2.07 in
